Aerospace Parts

Connecting Holder

MATERIAL : AA 6061 - Aluminum Alloy
Size ; 90*30 CRITICAL PARAMETER
wall thickness of.045 to
a distance of 20 mm
Microns Special Process: Electro less nickel plating

Base

MATERIAL : 17-4 PH CASTING
Size ; 90*30 CRITICAL PARAMETER
Perpendicularity
Size: 340 mm Dia
TOLERANCE ; 20 Microns

Gimble

MATERIAL : AA, 6061 - Aluminum Alloy
Size ; 4.5" * 2.2" TOLERANCE ; 5 Microns
Bore
Positional tolerance between bores; 50
Microns
Special process ; Black anodizing
& chemical conversions

Main Housing

MATERIAL : 17-4 PH - CASTING
CRITICAL PARAMETER : Perpendicularity
Infernal Diameter,
Groove Width
Size ; 340 mm dia
Tolerance ; 12
Micrins, 18 Microns

Bushing Oil Feeed

MATERIAL : BS, S130D - Corrosion resistance steel
Size ; Dia 4040*12 CRITICAL DIMENSION : Diammeter
TOLERANCE ; +- 7
Microns

Space Washer

MATERIAL : BS, S130D - Corrosion resistance steel
Size ; Dia 27.5*7 CRITICAL PARAMETER : Thread
THREAD TYPE: Unified Form
Special

Plate Spacer

MATERIAL : BS, S130D -
Corrosion resistance steel Size ; Dia 34*4,8
CRITICAL DIMENSION : Diammeter
TOLERANCE ; +- 6
Microns

Weight, Trim Balance

MATERIAL : BS, S130D - Corrosion resistance steel
Size ; Dia 27.5*7
CRITICAL DIMENSION : Parallelism
TOLERANCE ; 25 Microns

Pin Relocating

MATERIAL : MSRR 7052 - Heat Resistance Steel
Size ; Dia 9*11.5
CRITICAL DIMENSION : Diameter
TOLERANCE ; +- 4 Microns

Dowel Hollow

MATERIAL : AMS5663 - Nicke
Alloy Size ; Dia 27.5*7
CRITICAL PARAMETER : Diameter
TOLERANCE ; +- 9 Microns

Pin

MATERIAL : MSRR 7052 - Heat Resistance Steel
Size ; Dia 8* 9,05 CRITICAL DIMENSION : Diameter
TOLERANCE ; +- 5 Microns

Valve Relief Oil

MATERIAL : BSS 151 - Heat - Resistance steel
Size ; Dia 25.92*5 CRITICAL PARAMETER : Surface Finish
TOLERANCE ; 0.1 Ra
